Overview

Create pixel-perfect imagery at a cost-conscious price point with the new fully commercial Sharp PN-ME2 Series large format displays. By focusing on bringing high-powered, integrated and easy-to-use media playback to the customer all while maintaining the proven reliability and quality of previous product, the ME series gives customers a reliable mainstream display to fit all of their digital signage needs. The flexible system-on-chip platform not only allows for high-end media playback via USB or internal storage but since these products are powered by Android 13, they also allow the ability to install separate APK’s if a third-party application needs to be installed. On top of this, the updated OSD design includes new and legacy functionality within a brand new aesthetically appealing and stylistic approach.

  • 4K UHD native resolution allows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
  • Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
  • Powerful System-on-Chip Design to fit your digital signage needs
  • Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C while supporting both legacy NEC and Sharp protocol
  • 450 cd/m² brightness and HDR compatibility will capture the attention of audience in almost any situation
  • Integrated Media Player allows for playlist creation and scheduled playback via USB or onboard storage
  • 18/7 commercial runtimes with built-in real-time clock and full scheduler capabilities
  • Integrated USB-C Connection that not only allows for DP-Alt mode but also upstream capabilities for controlling peripherals through the separate USB-A downstream connection
  • Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
  • Energy Star 8.0 Certified Product
  • Full 3 year commercial warranty to allow for peace of mind and protection of your investment/li>
  • NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations
  • Fully compatible with Crestron Connected® software as well as Crestron XiO Cloud® Service
Technologies expand_more

  • 4K Resolution
    Provides the ultimate in screen clarity.

  • Built-In Speakers
    Enhance the visual experience with superior sound

  • Integrated Ambient Light Sensor
    Integrated Ambient Light Sensor allows the display to automatically adjust its luminance based on the external brightness conditions, allowing for the ideal image in all ambient lighting scenarios.

  • Integrated MultiMedia Player
    Allows the ability to play video, audio or image files directly off USB.

  • Landscape/Portrait Capable
    Allows for distortion-free display of content in various orientations, creating new application opportunities.motion video.

  • LED Backlight
    Provides for industry-leading low power consumption and less hazardous materials.

  • RS-232C and LAN control capability
    Permits flexible remote-control capabilities from connected devices.

  • Three HDMI inputs
    Allows for simultaneous digital connections of high-definition sources.

  • TileComp™
    Automatically eliminates geometrical distortions between displays by adjusting for the width of the monitor bezels, working in tandem with TileMatrix (some data on the screen will be lost in the area of the bezels).

  • TileMatrix™
    • Allows users to customize a video wall configuration using advanced On Screen Display controls.

  • Wired Network Connection
    • Integrated RJ45 connection for quick connection to the LAN (10/100 base-T capability).

  • Wireless LAN (Optional)
    • Allows you to transmit images from a PC wirelessly to the projector, eliminating the need for traditional cumbersome cables.
Service Enhancements expand_more


3 Year Coverage

  • ADVEXMX-3Y-18: Advanced Exchange 2 Day Freight Service+
  • ONSTEMN-3Y-18: Onsite 2 Day Freight Service+

4 Year Coverage

  • ADVEXMX-4Y-18: Advanced Exchange 2 Day Freight Extended Warranty 4 Years
  • EXTWRMN-4Y-18: Extended Warranty 4 Years
  • ONSTEMN-4Y-18: Onsite 2 Day Freight Extended Warranty 4 Years​

5 Year Coverage

  • ADVEXMX-5Y-18: Advanced Exchange 2 Day Freight Extended Warranty 5 Years
  • EXTWRMN-5Y-18: Extended Warranty 5 Years
  • ONSTEMN-5Y-18: Onsite 2 Day Freight Extended Warranty 5 Years

Note: Extended warranties are not valid in personal residences.

Features

Optional:

  • Wall Mount (WMK-3298T)
  • IR/Human Sensor Accessory (KT-RC3)
  • Table Top Stand (ST-801)
  • Powered External Speaker (SP-RM3a)
  • 3m Power cord
  • 3.0m HDMI cable
  • Wireless remote control
  • Batteries
  • Setup Guide
3 years Advanced Exchange
Integrated Temperature Sensor
  • AMX Support
  • Automated Email Alert Function
  • ARC Support through HDMI1
  • CEC Support through all HDMI Connections
  • Crestron Roomview Support
  • Display Browser Control
  • Display Wall Calibrator Compatible
  • HDR Support (PQ, HLG, HDR10)
  • Key Guide
  • NaViSet Administrator 2 Compatible
  • Screen Rotation for Portrait Orientation (Home Only)
  • Power USB Ports (5V/3A x1, 5V/2A x2, 5V/0.5A x1)
  • Real Time Clock
  • TileMatrix
  • SNMP (Running Change)
  • Crestron Connected V2
  • Integrated Temperature Sensor
  • Integrated USB Media Player
  • Full Input Detect Functionality
  • Programmable Gamma
  • Energy Star 8.0
  • Scheduler Function
  • Color Tempearture Adjustment (2600K - 10000K)
  • Vacation Switch

Display
Panel Technology ADS
Viewable Image Size 98 inches
Aspect Ratio 16:9
Screen Resolution 3840x2160
Pixel Pitch 0.562 mm
Pixels Per Inch 45 @ native resolution
Backlight Type LED Direct-lit
Brightness (typical) 450 cd/m2
Contrast Ratio (typical) 1200:1
Viewing Angle (typical) 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR greater than 10
Response Time (typical) 8 ms
Refresh Rate 60Hz
Active Screen Area 84.99 x 47.81 in. / 2158.85 x 1214.35mm
Displayable Colors More than 1.07 billion (8-bit+FRC)
Color Gamut
Supported Resolutions USB-C: 640 x 480, 720 x 480, 720 x 576, 800 x 600, 1024 x 768, 1280 x 720, 1280 x 800, 1280 x 1024, 1360 x 768, 1366 x 768, 1400 x 1050, 1440 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 1920 x 1200, 1920 x 2160, 3840 x 2160, 4096 x 2160 | HDMI: 640 x 480, 720 x 480, 720 x 576, 800 x 600, 1024 x 768, 1280 x 720, 1280 x 800, 1280 x 1024, 1360 x 768, 1366 x 768, 1400 x 1050, 1440 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 1920 x 1200, 1920 x 2160, 3840 x 2160, 4096 x 2160
Orientation Landscape/Portrait
Color Temperature (Max) (°K) 10000K
Color Temperature (Min) (°K) 2600K
Gamma (Typical) Native, 2.2, 2.4, S-Gamma, DICOM Sim, Programmable
Dimming Capability
Synchronization Range
Horizontal (Digital) USB-C Alt Mode: 30 - 135kHz HDMI: 15 - 135KHz
Vertical Digital: 23.0 - 76.0Hz
Signal Compatibility
Supported Video Standards
Sync Compatiblity
PC Signal Compatibility Yes
Macintosh Signal Compatibility Yes
External Control LAN and RS232 In - Full external control capabilities
Video
Connectivity
Data
Power Delivery
Input Terminals - RGB1 (analog)
Input Terminals - Audio 1
Input Terminals - RGB1 (digital)
Input Terminals - RGB2 (digital)
Input Terminals - RGB3 (digital)
Output Terminals - Audio Out
Output Terminals - Monitor Out
Power Consumption (typical)
On 206.2W
Power Savings Mode 2W
Power Requirements
ECO Mode Standby Lesss than 0.5W
Network Standby 0.5W
Power Consumption (max) 333.6W (Max Brightness), 443.6W (Brightness Max, Volume Max)
Physical Specifications
Dimensions (with stand) (WxHxD)
Dimensions (without stand) (WxHxD) 86.6 x 49.4 x 2.7 in. / 2198.9 x 1254.6 x 68.6 mm
Dimensions (shipping) (WxHxD) 92.9 x 56.1 x 11.0 in. / 2360.0 x 1425.0 x 280.0mm
Net Weight (with stand)
Net Weight (without stand) 120.2 lbs. / 54.5 kg.
Weight (shipping) 180.8 lbs. / 82.0kg
VESA Hole Configuration 800 x 40 (M8 x 4-hole)
Bezel Width (Left/Right, Top/Bottom) 0.71 in./0.71 in., 0.71 in./0.71 in. : 18 mm/18 mm, 18 mm/18 mm
Environmental Conditions
Operating Temperature
Operating Humidity 20% to 80%
Operating Altitude 9843 ft. / 3000m
Storage Temperature -4-140°F / -20-60°C
Storage Humidity 10-80%
Storage Altitude 40,000 ft. / 12,192m
Environmental Compliance
ENERGYSTAR Energy Star 8.0
RoHS
TCO
Connectivity - Input Terminals
Digital HDMI (2.0 x 3 with HDCP), USB-C (DP Alt Mode)
Audio Digital TMDS / USB-C Alt Mode
External Control RS-232C, LAN (1000Mb), 3.5mm Mini-Jack (IR Remote)
Data USB 3.0 x1 (5V/0.9A, Downstream), USB 2.0 x1 (5V/0.5A, Downstream), USB 3.0 x1 (Downstream for USB-C), USB-C x1 (Upstream)
Connectivity - Output Terminals
Audio 3.5mm Mini-Jack, Optical Audio Out (SPDIF)
Digital
External Control
